AIRSPEED SERIES
The Airspeed line offers a variety of different design and color combinations for lighter traffic areas while delivering the world standard in quality and performance.
(Hand Dryer Planning Guide)



Features & Benefits Warranty Materials Mechanisms
Colors Available   Electrical Characteristics   Size and Weight   Installation Information

FEATURES & BENEFITS


  • Provides superior value
  • Delivers air velocity of 5300 linear feet per minute to ensure quick drying
  • Available in a wide variety of colored panel fronts (see color chart below), both surface and recessed mount


(Back to top) WARRANTY

  • 5 year limited parts warranty standard
  • 10 year limited parts warranty available


(Back to top) MATERIALS

  • Cover construction of .08" thick diecast zinc for durability and vandal resistance
  • Exposed areas are chrome plated or covered with a white chip-resistant epoxy finish for durability
  • Tamper resistant screws lock cover securely to base
  • All internal parts are plated with corrosion-resistant material


(Back to top) MECHANISMS

  • Units feature push button activation and a durable cam-operated timer to control drying duration
  • Shaded pole (brushless) motor with factory lubricated, self-aligning bearings operating at 1/10 HP and 3200 RPM, delivering 5300 LFM average air velocity

(Back to top) SPECIFICATION GUIDE
  Airspeed dryers shall include cover of diecast zinc alloy .08 inch thick. Cover to be finished with chrome plating or white epoxy paint. Motor shall be of shaded pole (brushless) type operating at maximum 3200 RPM at rated load, delivering 5300 linear feet of air per minute (LFM). Manual dryers will be operated by means of a push button control device and cam-operated timer. Recessed units will include a 16-gauge steel wall-mounting box. Hand dryers shall be listed under examination service of Underwriter's Laboratories, Inc. and certified by the Canadian Standards Association.

(Back to top)
AIRSPEED PUSH BUTTON SERIES Electrical Characteristics
Models Electrical Characteristics
Surface Models Recessed Models Drying Cycle Volts Amps Watts Hz
WA126 WR126 30 Sec. 120 17 2000 60
WA216 WR216 30 Sec. 208 10 2000 60
WA246 WR246 30 Sec. 240 8.5 2000 60
WA126-2 WR126-2 30 Sec. 120 13 1500 60
WA235 WR235 30 Sec. 230 8 1800 50*
*50Hz units available for Export Markets only.

(Back to top)
AIRSPEED SERIES Size and Weight Specifications
  Outer Dimensions Shipping Weight
Surface Models 10 29/32" W x 11 5/8" H x 7" D
(277mm x 295mm x 178mm)		 24 Lbs.
Recessed Models 12 3/4" W x 13 1/2" H x 5" D
(324mm x 343mm x 127mm)		 30 Lbs.


(Back to top)
AIRSPEED SERIES - Color Panel
